EC24
,

EC 24- 330 K- T5
(1) (2) (3) (4) (5) (6)

(1)
(2)
(3)
(4)
(5)
(6) "" --
%
0 1 -
1 10 -
2 100 -
3 1000 -
4 - -
5 - -
6 - -
7 - -
8 - -
9 - -
- - 20
- 0.01 10
- 0.1 5

% , Q, , , , . , , . , .
EC24-R027M-CC 0.027 M(20%)
[K(10%)]
40 50.0 500 0.02 520
EC24-R033M-CC 0.033 M(20%)
[K(10%)]
40 50.0 490 0.02 500
EC24-R039M-CC 0.039 M(20%)
[K(10%)]
40 50.0 480 0.02 500
EC24-R047M-CC 0.047 M(20%)
[K(10%)]
40 50.0 480 0.03 500
EC24-R056M-CC 0.056 M(20%)
[K(10%)]
40 50.0 470 0.045 460
EC24-R068M-CC 0.068 M(20%)
[K(10%)]
40 50.0 470 0.05 460
EC24-R082M-CC 0.082 M(20%)
[K(10%)]
40 50.0 470 0.05 460
EC24-R10K 0.10 M(20%)
[K(10%)]
40 25.2 470 0.08 700
EC24-R12K 0.12 M(20%)
[K(10%)]
40 25.2 450 0.08 700
EC24-R15K 0.15 M(20%)
[K(10%)]
40 25.2 430 0.09 700
EC24-R18K 0.18 M(20%)
[K(10%)]
40 25.2 410 0.10 700
EC24-R22K 0.22 M(20%)
[K(10%)]
40 25.2 380 0.12 700
EC24-R27K 0.27 M(20%)
[K(10%)]
40 25.2 360 0.15 680
EC24-R33K 0.33 M(20%)
[K(10%)]
40 25.2 350 0.16 680
EC24-R39K 0.39 M(20%)
[K(10%)]
40 25.2 320 0.18 680
EC24-R47K 0.47 M(20%)
[K(10%)]
40 25.2 300 0.26 650
EC24-R56K 0.56 M(20%)
[K(10%)]
40 25.2 280 0.38 500
EC24-R68K 0.68 M(20%)
[K(10%)]
40 25.2 250 0.42 500
EC24-R82K 0.82 M(20%)
[K(10%)]
40 25.2 200 0.55 450
EC24-1R0K 1.0 M(20%)
[K(10%)]
65 25.2 180 0.12 700
EC24-1R2K 1.2 M(20%)
[K(10%)]
50 7.96 165 0.18 700
EC24-1R5K 1.5 M(20%)
[K(10%)]
50 7.96 150 0.20 700
EC24-1R8K 1.8 M(20%)
[K(10%)]
70 7.96 125 0.23 655
EC24-2R2K 2.2 M(20%)
[K(10%)]
50 7.96 85 0.25 630
EC24-2R7K 2.7 M(20%)
[K(10%)]
60 7.96 80 0.28 595
EC24-3R3K 3.3 K(10%)
[J(5%)]
60 7.96 75 0.30 575
EC24-3R9K 3.9 K(10%)
[J(5%)]
60 7.96 65 0.32 555
EC24-4R7K 4.7 K(10%)
[J(5%)]
50 7.96 45 0.35 530
EC24-5R6K 5.6 K(10%)
[J(5%)]
50 7.96 36 0.40 500
EC24-6R8K 6.8 K(10%)
[J(5%)]
50 7.96 30 0.45 470
EC24-8R2K 8.2 K(10%)
[J(5%)]
50 7.96 28 0.55 425
EC24-100K 10 K(10%)
[J(5%)]
50 7.96 22 0.72 370
EC24-120K 12 K(10%)
[J(5%)]
50 2.52 20 0.80 350
EC24-150K 15 K(10%)
[J(5%)]
50 2.52 16 0.88 335
EC24-180K 18 K(10%)
[J(5%)]
50 2.52 15 1.00 315
EC24-220K 22 K(10%)
[J(5%)]
60 2.52 13 1.20 285
EC24-270K 27 K(10%)
[J(5%)]
60 2.52 11 1.35 270
EC24-330K 33 K(10%)
[J(5%)]
50 2.52 10 1.50 255
EC24-390K 39 K(10%)
[J(5%)]
50 2.52 9.5 1.70 240
EC24-470K 47 K(10%)
[J(5%)]
50 2.52 8.5 2.30 205
EC24-560K 56 K(10%)
[J(5%)]
60 2.52 7.5 2.60 195
EC24-680K 68 K(10%)
[J(5%)]
60 2.52 6.5 3.20 185
EC24-820K 82 K(10%)
[J(5%)]
60 2.52 6.0 3.50 175
EC24-101K 100 K(10%)
[J(5%)]
60 2.52 5.5 3.80 165
EC24-121K 120 K(10%)
[J(5%)]
75 0.796 5.4 3.80 160
EC24-151K 150 K(10%)
[J(5%)]
75 0.796 4.75 4.40 150
EC24-181K 180 K(10%)
[J(5%)]
75 0.796 4.35 5.0 140
EC24-221K 220 K(10%)
[J(5%)]
75 0.796 4.0 5.7 130
EC24-271K 270 K(10%)
[J(5%)]
70 0.796 3.7 6.5 120
EC24-331K 330 K(10%)
[J(5%)]
70 0.796 3.4 9.5 100
EC24-391K 390 K(10%)
[J(5%)]
70 0.796 2.8 10.5 95
EC24-471K 470 K(10%)
[J(5%)]
70 0.796 2.4 12.5 90
EC24-561K 560 K(10%)
[J(5%)]
70 0.796 2.2 14.5 85
EC24-681K 680 K(10%)
[J(5%)]
70 0.796 2.0 18.0 75
EC24-821K 820 K(10%)
[J(5%)]
60 0.796 1.6 23.7 65
EC24-102K 1000 K(10%)
[J(5%)]
60 0.796 1.15 30.0 60
